SCOTT Scotty 5000 - Fiber Optics 4

4 Maintenance
4--37
F--9999--8 Build 8 Issue 1
Fig. 4-38. Paper Trip Fiber Optic Sensor
4.3 Fiber Optics
The Scotty 5000 has four sets of fiber optic
sensors. Each set has an upper and lower optic.
4.3.1 Fiber Optic Sensor Locations
1. Paper Trip/Counter
Fig. 4 -39. Paper Press Fiber O ptic Sensor
2. Paper Press
Fig. 4 -40. Paper Stop (Out of Stop) Fiber Optic
Sensor
3. Paper Stop (Out of Stop)
