SCOTT Scotty 5000 - METRIC HANDWHEEL SET-UPS for A4 (297 Mm X 210 Mm) TAB SIDE: 210 MM MARGIN: 1 MM

3-63
F--9999--8 Issue 1
METRIC HANDWHEEL SET-UPS FOR A4 (297mm x 210mm) TAB SIDE: 210 MM MARGIN: 1 MM
NOTE: SHADED AREAS ARE ACHIEVED BY TURNING THE STOCK UPSIDE DOWN. THE MIDDLE TAB IS JUST TO THE LEFT OF THE SHADED AREA.
END T AB POSITIONS ONL Y ALL OTHER TAB POSITIONS
TAB
BANK
T ABS TAB
SIZE
PLASTIC
LENGTH
PLASTIC
POSITION
TAB
POSITION
PLASTIC
LENGTH
POSITION
DIMENSION
2 -- 104.00 114.00 59.00 53.00 --
3 1&3 69.25 79.25 41.50 35.50 88.25 2
105.00
4 1&4 52.00 62.00 33.00 27.00 71.00 2 3
79.00 79.00
5 1&5 41.50 51.50 27.75 21.75 60.50 2 3 4
63.50 105.00 63.50
6 1&6 34.50 44.50 24.25 18.25 53.50 2 3 4 5
52.75 87.25 87.25 52.75
7 1&7 29.50 39.50 21.75 15.75 48.50 2 3 4 5 6
46.00 75.50 105.00 75.50 46.00
8 1&8 26.00 36.00 20.00 14.00 45.00 2 3 4 5 6 7
40.00 66.00 92.00 92.00 66.00 40.00
9 1&9 23.00 33.00 18.50 12.50 42.00 2 3 4 5 6 7 8
36.00 59.00 82.00 105.00 82.00 59.00 36.00
10 1&10 20.75 30.75 17.25 11.25 39.75 2 3 4 5 6 7 8 9
32.00 52.75 83.50 100.75 100.75 83.50 52.75 32.00
11 1&11 18.75 28.75 16.25 10.25 37.75 2 3 4 5 6 7 8 9 10
30.00 48.75 67.50 86.25 105.00 86.25 67.50 48.75 30.00
12 1&12 17.25 27.25 15.50 9.50 36.25 2 3 4 5 6 7 8 9 10 11
26.75 44.00 61.25 78.50 95.75 95.75 78.50 61.25 44.00 26.75
13 1&13 16.00 26.00 15.00 9.00 35.00 2 3 4 5 6 7 8 9 10 11 12
25.00 41.00 57.00 73.00 89.00 105.00 89.00 73.00 57.00 41.00 25.00
14 1&14 14.75 24.75 14.25 8.25 33.75 2 3 4 5 6 7 8 9 10 11 12 13
23.00 37.75 52.50 67.25 82.00 96.75 96.75 82.00 67.25 52.50 37.75 23.00
15 1&15 13.75 23.75 13.75 7.75 32.75 2 3 4 5 6 7 8 9 10 11 12 13 14
22.50 36.25 50.00 63.75 77.50 91.25 105.00 91.25 77.50 63.75 50.00 36.25 22.50
