SCOTT Scotty 5000 - METRIC HANDWHEEL SET-UPS for A4 (297 Mm X 210 Mm) TAB SIDE: 297 MM MARGIN: 0 MM

3-60
F--9999--8 Issue 1
METRIC HANDWHEEL SET-UPS FOR A4 (297mm x 210mm) TAB SIDE: 297 MM MARGIN: 0 MM
NOTE: SHADED AREAS ARE ACHIEVED BY TURNING THE STOCK UPSIDE DOWN. THE MIDDLE TAB IS JUST TO THE LEFT OF THE SHADED AREA.
END T AB POSITIONS ONL Y ALL OTHER TAB POSITIONS
TAB
BANK
T ABS TAB
SIZE
PLASTIC
LENGTH
PLASTIC
POSITION
TAB
POSITION
PLASTIC
LENGTH
POSITION
DIMENSION
2 -- 148.50 158.50 84.25 74.25 --
3 1&3 99.00 109.00 59.50 49.50 118.00 2
148.50
4 1&4 74.25 84.25 47.00 37.00 93.25 2 3
111.25 111.25
5 1&5 59.25 69.25 39.50 29.50 78.25 2 3 4
89.25 148.50 89.25
6 1&6 49.50 59.50 34.75 24.75 68.50 2 3 4 5
74.25 123.75 123.75 74.25
7 1&7 42.25 52.25 31.00 21.00 61.25 2 3 4 5 6
64.00 106.25 148.50 106.25 64.00
8 1&8 37.00 47.00 28.50 18.50 56.00 2 3 4 5 6 7
55.50 92.50 129.50 129.50 92.50 55.50
9 1&9 33.00 43.00 26.50 16.50 52.00 2 3 4 5 6 7 8
49.50 82.50 115.50 148.50 115.50 82.50 49.50
10 1&10 29.50 39.50 24.75 14.75 48.50 2 3 4 5 6 7 8 9
44.25 73.75 113.25 138.00 138.00 113.25 73.75 44.25
11 1&11 27.00 37.00 23.50 13.50 46.00 2 3 4 5 6 7 8 9 10
40.50 67.50 94.50 121.50 148.50 121.50 94.50 67.50 40.50
12 1&12 24.75 34.75 22.25 12.25 43.75 2 3 4 5 6 7 8 9 10 11
37.00 61.75 86.50 111.25 136.00 136.00 111.25 86.50 61.75 37.00
13 1&13 22.75 32.75 21.25 11.25 41.75 2 3 4 5 6 7 8 9 10 11 12
34.75 57.50 80.25 103.00 125.75 148.50 125.75 103.00 80.25 57.50 34.75
14 1&14 21.00 31.00 20.50 10.50 40.00 2 3 4 5 6 7 8 9 10 11 12 13
31.50 52.50 73.50 94.50 115.50 136.50 136.50 115.50 94.50 73.50 52.50 31.50
15 1&15 19.75 29.75 19.75 9.75 38.75 2 3 4 5 6 7 8 9 10 11 12 13 14
30.00 49.75 69.50 89.25 109.00 128.75 148.50 128.75 109.00 89.25 69.50 49.75 30.00
