SCOTT Scotty 5000 - METRIC HANDWHEEL SET-UPS for A4 (297 Mm X 210 Mm) TAB SIDE: 297 MM MARGIN: 1 MM

3-62
F--9999--8 Issue 1
METRIC HANDWHEEL SET-UPS FOR A4 (297mm x 210mm) TAB SIDE: 297 MM MARGIN: 1 MM
NOTE: SHADED AREAS ARE ACHIEVED BY TURNING THE STOCK UPSIDE DOWN. THE MIDDLE TAB IS JUST TO THE LEFT OF THE SHADED AREA.
END T AB POSITIONS ONL Y ALL OTHER TAB POSITIONS
TAB
BANK
T ABS TAB
SIZE
PLASTIC
LENGTH
PLASTIC
POSITION
TAB
POSITION
PLASTIC
LENGTH
POSITION
DIMENSION
2 -- 147.00 157.50 80.75 74.75 --
3 1&3 98.00 108.25 56.00 50.00 117.25 2
148.50
4 1&4 73.75 83.75 43.75 37.75 92.75 2 3
111.50 111.50
5 1&5 59.00 69.00 36.50 30.50 78.00 2 3 4
89.50 148.50 89.50
6 1&6 49.00 59.00 31.50 25.50 68.00 2 3 4 5
74.50 123.50 123.50 74.50
7 1&7 42.00 52.00 28.00 22.00 61.00 2 3 4 5 6
64.50 106.50 148.50 106.50 64.00
8 1&8 36.75 46.75 25.25 19.25 55.75 2 3 4 5 6 7
56.00 92.75 129.50 129.50 92.75 56.00
9 1&9 32.75 42.75 23.25 17.25 51.75 2 3 4 5 6 7 8
50.25 83.00 115.75 148.50 115.75 83.00 50.25
10 1&10 29.50 39.50 21.75 15.75 48.50 2 3 4 5 6 7 8 9
45.25 74.75 114.25 136.00 136.00 114.25 74.75 45.25
11 1&11 26.75 36.75 20.25 14.25 45.75 2 3 4 5 6 7 8 9 10
41.50 68.25 95.00 121.75 148.50 121.75 95.00 68.25 41.50
12 1&12 24.50 34.50 19.25 13.25 43.50 2 3 4 5 6 7 8 9 10 11
37.50 62.25 86.75 111.25 135.75 135.75 111.25 86.75 62.25 37.50
13 1&13 22.50 32.50 16.25 12.25 41.50 2 3 4 5 6 7 8 9 10 11 12
36.00 58.50 81.00 103.50 126.00 148.50 126.00 103.50 81.00 58.50 36.00
14 1&14 21.00 31.00 17.50 11.50 40.00 2 3 4 5 6 7 8 9 10 11 12 13
32.50 53.50 74.50 95.50 116.50 137.50 137.50 116.50 95.50 74.50 53.50 32.50
15 1&15 19.50 29.50 16.75 10.75 38.50 2 3 4 5 6 7 8 9 10 11 12 13 14
31.50 51.00 70.50 90.00 109.50 129.00 148.50 129.00 109.50 90.00 70.50 51.00 31.50
