SCOTT Scotty 5000 - Handwheel Set-Ups for 11 Sheet with 1;8 Margins

3-50
F--9999--8 Issue 1
HANDWHEEL SET-UPS FOR 11” SHEET WITH
1
/
8
” MARGINS
NOTE: SHADED AREAS ARE ACHIEVED BY TURNING THE STOCK UPSIDE DOWN. THE MIDDLE TAB IS JUST TO THE LEFT OF THE SHADED AREA.
END T AB POSITIONS ONL Y ALL OTHER TAB POSITIONS
TAB
BANK
TAB
SIZE
TABS
PLASTIC
LENGTH
PLASTIC
POSITION
TAB
POSITION
PLASTIC
LENGTH
PLASTIC & TAB POSITIONS
3 3.58 1&3 4.08 2.06 1.91 4.33
2
5.50
4 2.69 1&4 3.19 1.61 1.47 3.44
2 3
4.16 4.16
5 2.15 1&5 2.65 1.35 1.20 2.90
2 3 4
3.35 5.50 3.35
6 1.79 1&6 2.29 1.17 1.02 2.54
2 3 4 5
2.81 4.60 4.60 2.81
7 1.54 1&7 2.04 1.04 .89 2.29
2 3 4 5 6
2.43 3.97 5.50 3.97 2.43
8 1.34 1&8 1.84 .94 .79 2.09
2 3 4 5 6 7
2.14 3.49 4.84 4.84 3.49 2.14
9 1.19 1&9 1.69 .87 .72 1.94
2 3 4 5 6 7 8
1.91 3.10 4.30 5.50 4.30 3.10 1.91
10 1.07 1&10 1.57 .80 .66 1.82
2 3 4 5 6 7 8 9
1.74 2.81 3.89 4.96 4.96 3.89 2.81 1.74
11 .98 1&11 1.48 .76 .60 1.73
2 3 4 5 6 7 8 9 10
1.58 2.56 3.54 4.52 5.50 4.52 3.54 2.56 1.58
12 .90 1&12 1.40 .72 .56 1.65
2 3 4 5 6 7 8 9 10 11
1.46 2.36 3.26 4.16 5.06 5.06 4.16 3.26 2.36 1.46
13 .83 1&13 1.33 .69 .53 1.58
2 3 4 5 6 7 8 9 10 11 12
1.36 2.19 3.02 3.85 4.68 5.50 4.68 3.85 3.02 2.19 1.36
14 .77 1&14 1.27 .66 .50 1.52
2 3 4 5 6 7 8 9 10 11 12 13
1.27 2.04 2.81 3.58 4.35 5.12 5.12 4.35 3.58 2.81 2.04 1.27
15 .72 1&15 1.22 .63 .47 1.47
2 3 4 5 6 7 8 9 10 11 12 13 14
1.19 1.91 2.63 3.35 4.07 4.79 5.50 4.79 4.07 3.35 2.63 1.91 1.19
