SCOTT Scotty 5000 - Run Production; Paper Stocks 4

3 Operation
3--30
F--9999--8 Build 8 Issue 1
BAD FILM
SEAL
Fig. 3-59. Film Seal
Film Seal (adhesion to stock)
● Heat or seal time
● Bad film
● Bad paper stock
If needed make necessary adjustments and repeat
till problem is corrected.
Note ! The film may not adhere to some
coated stocks. Aqueous and
Varnished stocks tend to release gas
when laminated and cause bubbles in
the film. Also, coated stocks tend to
isolate the film from the paper not
allowing the plastic to adhere to the
paper fibers.
COUNTER
Fig. 3 -60. Feeder Counter
3.3.8 Run Production
Step: 1. Set counter to desired quantity of sheets
to be run.
Step: 2. Push Counter On/Off button to start
counting.
RUN
SAFE
Fig. 3 -61. Key Switch
Step: 3. Turn key switch to RUN.
RESET
Fig. 3-62. Reset Pushbutton
Step: 4. Press RESET pushbutton.
