SCOTT Scotty 5000 - Handwheel Set-Ups for 5 Sheet with 3;16 Margins

3-36
F--9999--8 Issue 1
HANDWHEEL SET-UPS FOR 5” SHEET WITH
3
/
16
” MARGINS
NOTE: SHADED AREAS ARE ACHIEVED BY TURNING THE STOCK UPSIDE DOWN. THE MIDDLE TAB IS JUST TO THE LEFT OF THE SHADED AREA.
END T AB POSITIONS ONL Y ALL OTHER TAB POSITIONS
TAB BANK TAB SIZE T ABS PLASTIC
LENGTH
PLASTIC
POSITION
TAB
POSITION
PLASTIC
LENGTH
PLASTIC & TAB POSITIONS
3 1.54 1&3 2.15 1.03 .96 2.29
2
2.50
4 1.16 1&4 1.77 .84 .77 1.91
2 3
1.92 1.92
5 .93 1&5 1.54 .72 .65 1.68
2 3 4
1.57 2.50 1.57
6 .77 1&6 1.48 .64 .57 1.52
2 3 4 5
1.34 2.11 2.11 1.34
