SCOTT Scotty 5000 - Handwheel Set-Ups for 7-1;4 Sheet with 3;16 Margins

3-38
F--9999--8 Issue 1
HANDWHEEL SET-UPS FOR 7-1/4” SHEET WITH
3
/
16
” MARGINS
NOTE: SHADED AREAS ARE ACHIEVED BY TURNING THE STOCK UPSIDE DOWN. THE MIDDLE TAB IS JUST TO THE LEFT OF THE SHADED AREA.
END T AB POSITIONS ONLY ALL OTHER TAB POSITIONS
TAB
BANK
TAB
SIZE
T ABS
PLASTIC
LENGTH
PLASTIC
POSITION
TAB
POSITION
PLASTIC
LENGTH
PLASTIC & TAB POSITION
3 2.29 1&3 2.83 1.43 1.33 3.04 2
3.63
4 1.72 1&4 2.26 1.15 1.05 2.47 2 3
2.76 2.76
5 1.38 1&5 1.92 .93 .88 2.13 2 3 4
2.25 3.63 2.25
6 1.15 1&6 1.69 .86 .76 1.90 2 3 4 5
1.90 3.05 3.05 1.90
7 .98 1&7 1.52 .78 .68 1.73 2 3 4 5 6
1.66 2.64 3.63 2.64 1.66
8 .86 1&8 1.40 .72 .62 1.61 2 3 4 5 6 7
1.48 2.33 3.19 3.19 2.33 1.48
9 .76 1&9 1.30 .67 .57 1.51 2 3 4 5 6 7 8
1.33 2.09 2.86 3.63 2.86 2.09 1.33
10 .69 1&10 1.23 .63 .53 1.44 2 3 4 5 6 7 8 9
1.22 1.90 2.59 3.28 3.28 2.59 1.90 1.22
11 .63 1&11 1.17 .60 .50 1.38 2 3 4 5 6 7 8 9 10
1.13 1.75 2.38 3.00 3.63 3.00 2.38 1.75 1.13
12 .57 1&12 1.10 .57 .47 1.32 2 3 4 5 6 7 8 9 10 11
1.05 1.62 2.19 2.76 3.33 3.33 2.76 2.19 1.62 1.05
13 .53 1&13 1.07 .55 .45 1.28 2 3 4 5 6 7 8 9 10 11 12
.98 1.51 2.04 2.56 3.09 3.63 3.09 2.56 2.04 1.51 .98
