3 Operation
3--29
F--9999--8 Build 8 Issue 1
3.3.7 Set Up For Production
PLASTIC SIZE
HANDWHEEL
PLASTIC POSITION
HANDWHEEL
TAB SIZE
HANDWHEEL
TAB POSITION
HANDWHEEL
PILE LIFT
HANDWHEEL
Fig. 3 -56. Set Handwheels for Tabs
Step: 1. Use the charts in the back of this section to set the machine up for the desired tabs.
Fig. 3-57. Heater Controls
Step: 2. If laminating plastic to paper, check heat
controls to see if they have reached their
operating temperature.
Note ! The starting point for the heaters is
220- 230
_
F. This may need to be
changed depending on thickness of
stock and the length or type of plastic.
BAD CUT
HIGH
TOPPING
Fig. 3-58. Test Sheets
Step: 3. Run at least 6 test sheets of stock.
Check each sheet for:
High Topping.
● Roller tension.
● Steel ball placement.
Cut (tab and edge of stock)
● Knife blade adjustment
● Dull knives
To Next Page
