5 SCOTTY 5000 PARTS
5.2 PILE FEED - REGISTER BOARD ADJUSTMENT
5-7
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 PF--0196--1 PLATE, FRONT SIDE, RH 1
2 PF--0195 PLATE, FRONT SIDE, LH 1
3
PF--0170--1 BAR, CROSS 2
HW--51230 SCREW, SHC 2
4
PF--0183 SCREW, ACME ADJUST 1
HW--57090 PIN, SPRING, 1
5
PF--0184 NUT, ACME 1
HW--82030 SCREW, LOCK 1
HW--49130 D--SHAPED WASHER 1
6 HW--51230 SCREW, SHC, 4
7 HW--81010 KNOB, 2
8
FP--0101 BAR, HOLD DOWN 1
HW--84080 BALL, STEEL, 10
9
PF--0159 CLAMP, PAPER HOLD, DOWN 2
HW--51100 SCREW, SHC, 4
10 HW--57190 PIN, SPRING 4
