5 SCOTTY 5000 PARTS

5.3 PILE FEED - DRIVE ROLLER ASSEMBLY

5-9

F--9999--8 08/2006 Issue 1

ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ

1 FP--0105 PLATE, SPRING 1

2 HW--53100 SCREW, BUTTON HD., 2

3 HW--55460 SCREW, THUMB, 1

4 FP--0104 CLAMP, ROLLER 1

5 HW--55075 SCREW, SHOULDER, 1

6 HW--67030 BEARING, NEEDLE 1

C--2151 WHEEL, PULL BACK 1

HW--74060 O--RING, 1

8 FP--0103 BLOCK, ROLLER 1
