5 SCOTTY 5000 PARTS
5.7 PILE FEED - VACUUM BAR
5-17
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 PF--0228 CUP, PICKUP NOZZLE 4
2 HW--61040 RING, R ETAINING 4
3 PF--0231 VACUUM, NOZZLE 4
4 HW--74020 O--RING 4
5 PF--0135 BAR, VACUUM 1
6 HW--55470 SCREW, THUMB, 8
7 PF--0151 PLUG 4
8 HW--51270 SCREW, SHC, 2
9 PF--0149 PLATE, RETAINING 2
10 PF--0148 FINGER, SPRING 6
