5 SCOTTY 5000 PARTS
5.8 PILE FEED - PAPER GUIDE
5-19
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--51120 SCREW, SHC 2
2 PF--0124 PLATE, HOLD DOWN ROLLER 2
3 HW--97010 FIBER, OPTIC 1
4 HW--66009 BEARING, BALL 8
5 HW--62010 RING, R ETAINING 8
6 PF--0123 ROLLER, PAPER HOLD DOWN 4
7 HW--74060 O--RING, PARKER 12
8 HW--56120 DOWEL, PIN 8
9 HW--57050 PIN, SPRING 4
10 HW--51210 SCREW, SHC 4
11 HW--61040 RING, RETAINING 4
12 HW--66020 BEARING, BALL 4
13 PF--0115 ROLLER, MAIN FEED 2
14 HW--51200 SCREW, SHC 6
15 FP--0102 BRACKET, SWITCH 1
16 PF--0232 BLOCK, PAPER SUPPORT PLATE 2
17 PF--0233--1 PLATE, PAPER SUPPORT 1
18 HW--51390 SCREW, SHC 2
19 HW--71050 ROLLER, YOKE 1
20 HW--49050 WASHER, FLAT 2
21 HW--86030 PULLEY, TIMING GEAR 1
22 HW--58010 KEY, WOODRUFF 2
23 PF--0122 PLATE, HOLD DOWN ROLLER 2
24 HW--61200 RING, RETAINING 12
25 PF--0127 BLOCK, SHAFT MTG. 1
26 HW--57200 PIN, SPRING 1
27
PF--0125 BLOCK, MOUNTING 2
HW--79090 SPRING, COMP 2
28
HW--81000 KNOB, 2
HW--55040 SCREW, SHOULDER 2
29 PF--0121 LEVER, ROLLER 2
30 PF--0126 SHAFT, PAPER HOLD 1
31 PF--8603--A PULLEY, TIMING GEAR 1
