5 SCOTTY 5000 PARTS
5.10 PILE HEIGHT ASSEMBLY
5-23
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--57140 PIN, SPRING, 1
2 HW--66020 BEARING, BALL 2
3 HW--61130 RING, RETAINER 2
4 HW--69090 THRUST, RACE 2
5
PF--0169 BLOCK, SHEET CHECK MTG. 1
HW--57190 PIN, SPRING, 2
6
HW--52080 SCREW, SET, 1
HW--84020 BALL, NYLON, 1
7
PF--0166 SHAFT, SHEET CHECK PIVOT 1
HW--57190 PIN, SPRING, 1
8
HW--81060 BALL 1
HW--60140 NUT,JAM, 1
HW--52250 SCREW, SET, 1
9 HW--70030 ROD, END FEMALE 2
10 HW--51370 SCREW, SHC., 2
11
PF--0194 CONNECTING ROD 1
HW--60130 NUT,JAM, 2
12
HW--80050 SPRING, EXTENSION, 1
HW--80025 SPRING, EXTENTION, 1
13 HW--57110 PIN, SPRING, 1
14
PF--0165 ROCKER, ARM 1
HW--57030 PIN, SPRING, 1
15 HW - -61110 RING, RETAINING 1
16
PF--0168 GUIDE, SIDE RACK 1
HW--51230 SCREW, SHC., 2
17 PF--0167 BAR, PILE HEIGHT CHANGE 1
18 HW--51230 SCREW, SHC., 2
19 HW--57190 PIN, SPRING, 2
20 HW--61190 RING, GRIP 4
