5 SCOTTY 5000 PARTS
5.11 PILE LIFT DRIVE
5-25
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
PF--0193 SUPPORT, PAPER (STANDARD) 3
PF--0246 SUPPORT, PAPER (LONG SHT. OPTION) 4
2
PF--0155 HORN, PAPER LIFT 1
HW--84020 BALL, NYLON 2
HW--52090 SCREW, SET 2
3 PF--7802 SHAFT, GUIDE 2
4 PF--0199 BAR, STACK SUPPORT 2
5
PF--0154 SLIDE, PAPER LIFT 1
HW--51410 SCREW, SHC 4
6 HW--57260 PIN, SPRING 2
7 PF--0236 SCREW, CHAIN 1
8
HW--77010 ROLLER, CHAIN 1
CONNECTING, LINK 1
9 HW--87060 SPROCKET, 1
10 HW--59030 KEY, SQUARE 1
11 HW--61050 RING, RETAINING 1
12 PF--0230 WEIGHT, CHAIN STACK 4
13 HW--57060 PIN, SPRING 1
14 HW--73020 SEAL 4
15 HW--65030 BUSHING, BALL 4
16 PF--0105 SHAFT, PILE LIFT 1
17 HW--57030 PIN, SPRING 2
To Next Page
