5 SCOTTY 5000 PARTS
5.13 PILE LIFT HANDWHEEL
5-29
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--63100 FITTING, GREASE, 1
2 HW--61050 RING, R ETAINING 6
3
PF--9801--A COLLAR 1
HW--79030 SPRING, COMP, 2
4 HW--69110 THRUST, RACE 1
5 HW--72030 ROLLER, CLUTCH 4
6 PF--0103 HOUSING, PILE LIFT 1
7 HW--69080 THRUST, RACE 7
8 PF--0102 HOUSING, ROCKER ARM 1
9 HW--67120 BEARING, NEEDLE 4
10 PF--0106 ROCKER, ARM 1
11 PF--8301 BUSHING 2
12 HW--82040 SCREW, LOCK 2
13 PF--0101 SHAFT, PILE LIFT 1
14 HW--59030 KEY, SQUARE 1
15 HW--88010 GEAR, BROWNING 1
16 PF--0104 GEAR, PILE LIFT, HANDWHEEL 1
17
PF--8101 HANDWHEEL 1
HW--52280 SCREW, SET CONEPOINT 1
18 HW--64010 BUSHING, BRONZE 2
19 HW--57200 PIN, SPRING 1
20
HW--71040 CAM, FOLLOWER 1
HW--60240 NUT, NYLON INSERT 1
21
HW--71060 ROLLER, YOKE 1
HW--51480 S C R E W , S H C 1
HW--49110 WASHER, 1
To Next Page
