5 SCOTTY 5000 PARTS
5.14 PILE FEED - SHEET SEPARATOR
5-31
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--56160 DOWEL, PULL 2
2
PF--0200 FITTING, BLOW AIR 2
HW--52010 SCREW, SET 2
HW--84010 BALL, NYLON 2
3 PF--0201 TUBE, BLOW AIR 2
4 PF--0204 TUBE, BLOW AIR 2
5 HW--61200 RING, R ETAINING 2
6 HW--74010 O--RING, PARKER 2
7
PF--0211 FITTING BLOW AIR 2
HW--51230 SCREW, SHC 4
8
PF--0131 GUIDE, SHEET STACK RH 1
HW--51200 SCREW, SHC 2
9
PF--0203 FITTING, BLOW AIR 2
HW--52010 SCREW, SET 2
HW--84010 BALL, NYLON 2
10 PF--0202 NOZZLE, FRONT BLOW AIR 2
11 HW--52080 SCREW, SET 1
12
PF--0225 PLATE, HOLDER 1
HW--51200 SCREW, SHC 2
13
PF--0226 BLOCK, SEPARATOR FINGER 1
HW--52080 SCREW, SET 1
HW--84020 BALL, NYLON 1
14 PF--0132--1 FINGER, SHEET SEPARATOR 2
15 PF--0133 BLOCK, STACK GUIDE MTG. 2
16 PF--0128 BAR, LIFT GUIDE MTG. 1
17 HW--52080 SCREW, SET 1
18
PF--0130 GUIDE, SHEET STACK LH 1
HW--51200 SCREW, SHC 2
19 HW--63360
ELBOW, MALE
2
