SCOTT Scotty 5000 - Page 168

5 SCOTTY 5000 PARTS
5.15 PILE FEED -- STACK GUIDE
5-33
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
PF--0172 NOZZLE, SIDE BLOW 2
HW--57050 PIN, SPRING, 2
2
PF--0173 BAR, STACK GUIDE MTG. 2
HW--57030 PIN, SPRING, 2
3
PF--0185 BLOCK, FEED GUIDE 2
HW--51210 SCREW, SHC, 4
4 HW--51100 SCREW, SHC, 4
5
PF--0174 BLOCK, NOZZLE MTG. 2
HW--84020 BALL, NYLON, 2
HW--52080 SCREW, SET, 2
6
PF--0175 BLOCK, CLAMP 2
HW--52220 SCREW, SET, 1
7 HW--51090 SCREW, SHC, 4
8
PF--0180 GUIDE, ST ACK RH (STANDARD) 1
PF--0244 GUIDE, ST ACK RH (LONG SHT. OPTION) 1
9 HW--81020 KNOB, 2
10
PF--0176 BAR, STACK GUIDE 2
HW--51210 SCREW, SHC, 4
11 PF--0179 GUIDE, STACK RH 1
12 PF--0178 GUIDE, STACK LH 1
13
PF--0181 GUIDE, ST ACK LH(STANDARD) 1
PF--0245 GUIDE, ST ACK LH(LONG SHT. OPTION) 1
14 KNOB, 1
15 PF--0177 BAR, PAPER GUIDE, SUPPORT 1
16 HW--63050 CONNECTOR, 2
