SCOTT Scotty 5000 - Page 182

5 SCOTTY 5000 PARTS
5.22 PLATEN UNIT
5-47
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
F--0801 FRAME, PLATEN 1
2
HW--56250
DOWEL, PIN, 4
3
HW--51470
SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
6
4
HW--51440 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
4
5
HW--56150 DOWEL, PIN PULL, 3
6
HW--95010 CHANNEL TRAC, 16
6
HW--53060 SCREW, BUTTON HD., 14
7
HW--53070 SCREW, BUTTON HD., 1
8
F--0813 BRACKET, SWITCH 1
9
F--0814--1 BRACKET, SWITCH 1
9
HW--51170 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
10
HW--51390 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
4
HW--49100 WASHER, FLAT 4
11
F--0802 PLATE, CYLINDER MOUNTING 1
12
F--0817 AIR CYLINDER, COMPACT 1
1
2
HW--63020 CONNECTOR, 2
13
HW--56150 DOWEL, PIN PULL, 2
14
HW--51370 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
15
F--0806 PLATE, MOUNTING 1
16
HW--51380 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
3
17
HW--51028 SCREW, SOC. HD. CAP
STEEL BLACK OXIDE
2
18
F--0809 BRACKET, CYLINDER 1
19
HW--51080 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
20
F--0818 AIR CYLINDER, COMPACT 1
21
F--0811 BRACKET, STOP 1
22
HW--53110 SCREW, BUTTON HD., 1
2
2
HW--49030 WASHER, FLAT, #10 STEEL 1
23
HW--53030 SCREW, BUTTON HD., 2
2
3
HW--49200 WASHER, STARWHEEL,
(INTERNAL TOOTH)
2
24
F--0804 PLATE, STOP 1
2
4
HW--54020 SCREW, SOC. FLAT HD., 4
25
F--0812 PLATE, RETAINING 1
2
5
HW--51080 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
3
26
F--0803 PLATEN 2
27
HW--51230 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
28
HW--51380 SCREW, SOC. HD. CAP
STEEL BLACK OXIDE
1
29
F--0807 SUPPORT, PLATEN 1
30
F--0816 BRACKET, SWITCH 1
3
0
HW - -51110 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
31
HW--51380 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
32
F--0808 STUD, PLATEN 1
33
F--0810 SHAFT, GUIDE 2
34
F--0805 BLOCK, GUIDE 1
35
F--0815 BRACKET, SWITCH 1
3
5
HW - -51110 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
36
HW--97010 FIBER PHOTOS 4
37
HW--63010 CONNECTOR, LEGRIS, 2
38
HW--94020 THERMOCOUPLE, 2
39
HEAT ELEMENT, 450 WATT 2
40
HW--97054 RECEPTACLE, MALE 2
41
F--0819 LABEL, CAUTION HOT 1
42
F--0821 BRACKET, SHIELD 1
43
F--0820 SHIELD, PAPER 1
4
3
HW--54010 SCREW, FLAT HD., 3
