SCOTT Scotty 5000 - Page 184

5 SCOTTY 5000 PARTS
5.23 REGISTER BOARD - HOLD DOWN PLATE
5-49
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 RB--0102 COVER, FEED BOARD 1
2 HW--51260 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
3 HW--53150 SCREW, BUTTON HD., 1
4
RB--0109 ROLLER, BELT BACK 1
HW--52080 SCREW, CUP POINT SOC. SET, 2
5 HW--86030 PULLEY, MARTIN
W/ SET SCREW
1
6 RB--0103--1 BAR,L.H.SIDEFRAME 1
7 RB--0110 SHAFT, PULLEY 1
8
RB--0101 BAR,L.H.MOUNTING 1
HW--51230 SCREW, SOC. HD. CAP 2
HW--57190 SPRING, PIN 2
9 HW--66010 BALL BEARING 4
10 RB--0106--1 BAR,R.H.SIDEFRAME 1
11
RB--0107 BAR,R.H.MOUNTING 1
HW--51230 SCREW, SOC. HD. CAP 2
HW--57190 SPRING, PIN 2
12
RB-- 0111 ROLLER, BELT FRONT 1
HW--52080 SCREW, CUP POINT SOC. SET, 2
13 RB--0108 SHAFT ROLLER 3
14
RB--0105--1 BAR, PAPER REGISTER 1
FB--0106 BAR, PAPER REGISTER 1
15
PLATE, HOLD DOWN 1
FB--0105 PLATE, HOLD DOWN 1
16
FB--0103 PLATE, PHOTO SWITCH 1
HW--51080 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
17 HW--97010 FIBER OPTICS 2
18 HW--51280 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
19 HW--84080 BALL, STEEL, 11
20 HW--51230 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
