SCOTT Scotty 5000 - Page 188

5 SCOTTY 5000 PARTS
5.25 MIDDLE REGISTER - HOLD DOWN PLATE
5-53
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 RB--0102 COVER, FEED BOARD 1
2 HW--51260 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
3 HW--53150 SCREW, BUTTON HD., 1
4
RB--0109 ROLLER, BELT BACK 1
HW--52080 SCREW, CUP POINT SOC. SET, 2
5 HW--86030 PULLEY, MARTIN
W/ SET SCREW
1
6 RB--0103--1 BAR,L.H.SIDEFRAME 1
7 F--2102 SHAFT, DRIVE 1
8 HW--66010 BALL BEARING 4
9 RB--0106--1 BAR,R.H.SIDEFRAME 1
10
RB-- 0111 ROLLER, BELT FRONT 1
HW--52080 SCREW, CUP POINT SOC. SET, 2
11 RB--0108 SHAFT ROLLER 3
12 HW--51230 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
13 F--2122 PLATE, HOLD DOWN 1
14 HW--51280 SCREW, SOC. HD. CAP,
STEEL BLACK OXIDE
2
15 HW--84080 BALL, STEEL, 10
