5 SCOTTY 5000 PARTS
5.28 MIDDLE REGISTER BOARD DRIVE (A)
5-59
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
HW--82030 SCREW, LOCK, 1
HW--49130 WASHER, D--SHAPE, 1
2 PF--0184 NUT, ACME 1
3 F--2151 PLATE, L.H. CENTER 1
4 HW--66060 BALL, BEARING 2
5 HW--53150 SCREW, BUTTON HD., 4
6 HW--51250 SCREW, SOC. HD. CAP, 16
7 HW--73030 SEAL 8
8 HW--65040 BUSHING, BALL 4
9 F--2155 BLOCK, BUSHING MOUNTING 4
10
F--2157 TUBE, DRIVE 1
HW--61080 RING, RETAINING 1
11 HW--97010 FIBER OPTICS 1
12
F--2159 BRACKET, SWITCH 1
HW--51230 SCREW, SOC. HD. CAP, 2
HW--49040 WASHER, FLAT, 2
13
HW--71030 ROLLER, YOKE 1
HW--51380 SCREW, SOC. HD. CAP, 1
HW--49050 WASHER, 1
14
F--2158 BLOCK, TENSION 1
HW--51380 SCREW, SOC. HD. CAP, 2
HW--49100 WASHER, HARDENED, 2
15 F--2152 PLATE, R.H. CENTER 1
16
HW--95088 CHANNEL TRAC, 3
HW--53140 SCREW, BUTTON HD., 3
17
F--2154 PULLEY, TIMING, 1
HW--52145 SCREW, SOC. SET, 1
18
PF--0183 SCREW, ADJUSTMENT 1
HW--57090 PIN, SPRING, 1
To Next Page
