5 SCOTTY 5000 PARTS
5.30 TAB CUTTER - KNIFE CARRIER (L.H.)
5-63
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
F--0505 LEVER, KNIFE 1
HW--51210 SCREW, SHC, 1/4-- 3
2
C--0524 KNIFE, UPPER L.H. 1
HW--54170 SCREW, FLAT HD., 3
3
HW--66300 BEARING, ROLLER 2
HW--66310 BEARING, ROLLER 2
4 F--0528 SCREW, SHOULDER 2
5 HW--64040 BEARING, BRONZE 4
6 HW--82030 SCREW, LOCKING 1
7 C--0507 NUT, ADJ. L.H. ACME THD. 1
8
C--0523 KNIFE, LOWER L.H 1
HW--54150 SCREW, FLAT HD., 5
9 F--0523 FRAME, KNIFE, L.H. 1
10 C--0527 PLATE, T -- NUT 5
11
F--0515 PLATE, NUT LONG 1
F--0520 SCREW, SHOULDER, 2
12
F--0526 KNIFE, CARRIER, L.H. 1
HW--52020 SCREW, SOC SET, 2
13 C--0564 LABEL, CAUTION, BLADE HAZARD 1
14 F--0532 GUIDE, MAGNET 1
