5 SCOTTY 5000 PARTS
5.31 TAB CUTTER - KNIFE CARRIER (R.H.)
5-65
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
F--0505 LEVER, KNIFE 1
HW--51210 SCREW, SOC. SET, 3
2
C--0525 KNIFE, UPPER R.H. 1
HW--54170 SCREW, FLAT HD., 2
3
F--0527 KNIFE, CARRIER, R.H. 1
HW--52020 SCREW, SOC SET, 2
4
HW--66300 BEARING, ROLLER 2
HW--66310 BEARING, ROLLER 2
5 F--0528 SCREW, SHOULDER 2
6 C--0527 PLATE, T--NUT 3
7 HW--64040 BEARING, BRONZE 4
8
C--0526 KNIFE, LOWER R.H. 1
HW--54150 SCREW, FLAT HD., 3
9 F--0525 FRAME, KNIFE, R.H. 1
10 C--0215 NUT, ADJ. R.H. ACME THD. 1
11 HW--82030 SCREW, LOCKING 1
12
F--0516 PLATE, NUT SHORT 1
F--0520 SCREW, SHOULDER, 2
13 C--0564 LABEL, CAUTION, BLADE HAZARD 1
14 F--0532 GUIDE, MAGNET 1
