5 SCOTTY 5000 PARTS
5.32 TAB CUTTER (A)
5-67
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 F--0511 ROLLER, RUBBER 4
2 F--0512 SHAFT, ROLLER 2
3 F--0501 PLATE, REAR L.H. 1
4 HW--51480 SCREW, SOC. HD. CAP, 12
5 HW--56270 DOWEL, PIN, 4
6 F--0513 PULLEY, TIMING 2
7 HW--61040 RING, R ETAINING 4
8 HW--66020 BEARING, BALL 4
9
HW--53140 SCREW, BUTTON HD., 4
HW--49040 WASHER, FLAT, 4
10 F--0510 SHAFT, BRACE 2
11
C--0553--C PLATE, CENTER TIE 1
HW--52100 SCREW, SOC. SET, 2
HW--84020 BALL, NYLON, 2
12 F--0502 PLATE, REAR R.H. 1
To Next Page
