5 SCOTTY 5000 PARTS
5.34 TAB CUTTER DRIVE LINKAGE
5-71
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--51570 SCREW, SOC. HD. CAP, 2
2 HW--60150 NUT, HEX HD. JAM, 4
3 HW--70050 ROD END, FEMALE 2
4 F--0508 ROD, TIE 2
5 HW--60160 NUT, HEX HD. JAM L.H., 2
6 HW--51560 SCREW, SOC. HD. CAP, 2
7 HW--70060 ROD END, FEMALE L.H. 2
8
F--0509 BLOCK, MOUNTING 1
HW--51580 SCREW, SOC. HD CAP, 4
9 F--0507 CYLINDER, AIR 1
10 F--0506--2 BLOCK, SPACER 1
11
HW--51590 SCREW, SOC. HD. CAP, 4
HW--49072 WASHER, FLAT, 4
12
HW--51480 SCREW, SOC. HD. CAP, 4
HW--49060 WASHER, FLAT, 4
13 HW--60260 NUT, LOCK, 2
14
HW--60220 NUT, LOCK, 4
HW--49060 WASHER, FLAT, 4
15 HW--97040 REED SENSOR 1
16 HW--63040 ELBOW, 2
17 F--0521 INSERT 2
To Next Page
