SCOTT Scotty 5000 - Page 210

5 SCOTTY 5000 PARTS
5.36HANDWHEELUNIT/PLASTICPOSITION/TABPOSITION
5-75
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--61030 RING, RETAINING, 4
2 C--0735 HANDLE 2
3 C--0733 ROD, HANDLE 2
4 HW--61010 RING, RETAINING, 6
5 C--0706 ROD, PINION 2
6 HW--53150 SCREW, BUTTON HD., 2
7 HW--49040 WASHER, FLAT, SAE 2
8
C--0703 TURNCAP 2
C--0748 LABLE, OUTER DIAL SCALE 2
9 RING, RETAINING, 6
10 HW--67010 BEARING, NEEDLE, 2
11 C--8808 GEAR, PINION 2
12 C--8802 GEAR, POSITIONING 2
13 HW--51150 SCREW, SOC. HD. CAP 8
14 BUSHING, STD. 2
15 BUSHING, STD. 2
16 HW--79110 SPRING, 2
17 C--0734 PLUNGER 2
18 HW--57110 PIN, SPRING 2
19 C--8803 VERNIER, RING SETTING 2
20 HW--67080 BEARING, NEEDLE, 4
21 C--0732 SPACER 2
22 HW--67140 BEARING, NEEDLE, 2
23
C--0707 RING, VERNIER 2
C--0749 LABLE, INNER DIAL SCALE 2
24 HW--51080 SCREW, SOC. HD. CAP, 8
25 C--0702 PLUG, FRICTION 6
26 HW--79040 SPRING, 6
27 C--0704 PLATE, BACKING 2
28
C--0705 SPACER (REGISTER PLATE) 1
C--0705 SPACER (MIDDLE REGISTER PLATE) 1
29 HW--51210 SCREW, SOC. HD. CAP, 4
30 HW--66020 BEARING, BALL, 2
31 HW--58010 KEY, WOODRUFF, 2
32
PF--0182 SHAFT, EXTENSION (REGISTER BOARD) 1
PF--0182 SHAFT, EXTENSION
(MIDDLE REGISTER BOARD)
1
33 HW--69175 THRUST RACE 2
34 PF--0183 SCREW, ADJUSTMENT 2
35 HW--57090 PIN, SPRING, 2
