SCOTT Scotty 5000 - Page 212

5 SCOTTY 5000 PARTS
5.37 HANDWHEEL UNIT/ PLASTIC SIZE
5-77
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--61030 RING, RETAINING, 2
2 C--0735 HANDLE 1
3 C--0733 ROD, HANDLE 1
4 HW--61010 RING, RETAINING, 3
5 C--0706 ROD, PINION 1
6 HW--53150 SCREW, BUTTON HD., 1
7 HW--49040 WASHER, FLAT, SAE 1
8
C--0703 TURNCAP 1
C--0748 LABLE, OUTER DIAL SCALE 1
9 HW- -61110 RING, RETAINING, 3
10 HW--67010 BEARING, NEEDLE, 1
11 C--8808 GEAR, PINION 1
12 C--8802 GEAR, POSITIONING 1
13 HW--51150 SCREW, SOC. HD. CAP, 4
14 BUSHING, STD. 1
15 BUSHING, STD. 1
16 HW--79110 SPRING, 1
17 C--0734 PLUNGER 1
18 HW--57110 PIN, SPRING, 1
19 C--8803 VERNIER, RING SETTING 1
20 HW--67080 BEARING, NEEDLE, 2
21 C--0732 SPACER 1
22 HW--67140 BEARING, NEEDLE, 1
23
C--0707 RING, VERNIER 1
C--0749 LABLE, INNER DIAL SCALE 1
24 HW--51080 SCREW, SOC. HD. CAP, 4
25 C--0702 PLUG, FRICTION 3
26 HW--79040 SPRING, 3
27 C--0704 PLATE, BACKING 1
28 C--0705 SPACER (PLASTIC DIAL) 1
29 HW--51210 : SCREW, SOC. HD. CAP, 2
30 HW--66020 BEARING, BALL, 1
31 HW--58010 KEY, WOODRUFF, 1
32 C--0217 SHAFT, EXTENSION (PLASTIC DIAL) 1
33 HW--69175 THRUST RACE 1
34 C--0216 SCREW, ADJUSTMENT 1
35 C--0232 COUPLING 1
36 HW--57030 PIN, SPRING, 2
