5 SCOTTY 5000 PARTS
5.40 PLASTIC FEED UNIT ASSEMBLY (A)
5-83
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--53150 SCREW, BUTTON HD., 2
2 C--0136 PLATE, SLIP CLUTCH 1
3 C--0137 DISC, BRAKE 1
4 HW--72020 ROLLER, CLUTCH 1
5
C--0124--1 ROLLER 1
HW--51120 SCREW, SOC. HD. CAP, 2
6 HW--53160 SCREW, BUTTON HD., 4
7 C--0116 PLATE 1
8 C--8801--A GEAR, FEED ROLLER 1
9 HW--79130 SPRING, COMPRESSED, 1
10 HW--57200 PIN, SPRING, 2
11 HW--51230 SCREW, SOC. HD. CAP, 4
12 HW--61060 RING, RETAINING 2
13 HW--67130 BEARING, NEEDLE 2
14 C--0129 PLATE, ROLLER MOUNTING 1
15 HW--67070 BEARING, NEEDLE 2
16 HW--69070 THRUST RACE, 2
17 HW--68010 THRUST BEARING, 1
18 HW--50010 STUD, THREADED 1
19 HW--81060 KNOB, PLASTIC BALL, 1
20 C--0122 BLOCK, SPACER 2
21
HW--52080 SCREW, SET, 2
HW--84020 BALL, NYLON, 2
22 HW--79150 SPRING, COMPRESSED, 1
23 C--0123 BLOCK, UPPER FEED 1
24 HW--80100 SPRING, 1
25 HW--57210 PIN, SPRING, 1
26
27 HW--57030 PIN, SPRING, 1
28 C--0130 SHAFT, BELT TENSION 1
29 C--0119 SHAFT 1
30 HW--61030 RING, RETAINING 2
31 C--0128 PLATE, SLIDE MOUNTING 1
32 C--0110 ROD, PIVOT 1
33 HW--51200 SCREW, SOC. HD. CAP, 4
34 HW--57170 PIN, SPRING 2
35 C--0121 SHAFT, UPPER 1
36 HW--69140 THRUST RACE 1
37 HW--67030 BEARING, NEEDLE 2
38 HW--86020 PULLEY, TIMING GEAR, 1
