SCOTT Scotty 5000 - Page 222

5 SCOTTY 5000 PARTS
5.42 PLASTIC FEED ASSEMBLY (C)
5-87
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
C--0133 SPACER, PLASTIC FEED MOUNTING 1
HW--51250 SCREW, SOC. HD. CAP, 4
HW--57260 PIN, SPRING, 2
2
F--0102 BAR, PLASTIC TENSION ROLLER MTG. 1
HW--53160 SCREW, BUTTON HD., 2
3 HW--55090 SCREW, SHOULDER, 1
4 C--0125 ROLLER, DRAG 1
5 HW--69160 THRUST RACE 1
6
C--0113 POST, SPACER 1
HW--51210 SCREW, SOC HD. CAP, 1
7
C--0114 LINK, CLUTCH 1
HW--51200 SCREW, SOC. HD. CAP, 1
8 HW--57030 PIN, SPRING, 1
9 HW--52350 SCREW, SOC SET
W/ NYLON TIP
1
10 HW--76010 BELT, GEAR 1
11 F--0101 KNOB, ADJUSTABLE 1
