5 SCOTTY 5000 PARTS
5.43 PLASTIC FEED UNIT - ROLLERS
5-89
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--55200 KNOB, KNURLED, 1
2 HW--53180 SCREW, BUTTON HD., 2
3 HW--69140 THRUST RACE 2
4 HW--67070 BEARING, NEEDLE 4
5 C--0117 SHAFT, FOLDING ROLLER 2
6 HW--81070 KNOB, KNURLED 1
7 HW--52150 SCREW, SOC SET, 1
8 C--0138 BRACKET, SENSOR 1
9 HW--97030 SENSOR, ULTRASONIC 1
To Next Page
