5 SCOTTY 5000 PARTS
5.44 PLASTIC FEED - SLIDE
5-91
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--69160 RACE, THRUST 1
2 HW--57170 PIN, SPRING, 2
3 HW--51240 SCREW, SOC. HD. CAP, 4
4 C--0109 BLOCK, PLASTIC FEED SLIDE 2
5 C--7801 ROD, SLIDE 2
6 HW--73010 SEAL, THOMSON 4
7 HW--65010 BUSHING, BALL 4
8 HW--63080 PLUG, 1
9
C--0112 CLAMP, TIMING BELT 1
HW--51090 SCREW, SOC. HD., CAP, 1
10 HW--63100 FITTING, GREASE, 1
11 HW--71010 CAM, FOLLOWER 1
12 HW--60090 NUT, HEX HD., 1
13 C - -0111 SLIDE 1
To Next Page
