SCOTT Scotty 5000 - Page 228

5 SCOTTY 5000 PARTS
5.45 PLASTIC FEED - DRIVE
5-93
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--66010 BEARING, BALL 2
2 C--0104 BLOCK, ROCKER ARM MOUNTING 2
3
C--0103 ARM, ROCKER 2
HW--57250 PIN, SPRING, 2
HW--52080 SCREW, SET, 1
HW--84020 BALL, NYLON, 1
4
HW--70030 ROD END, FEMALE 4
HW--60070 NUT, HEX, 4
5 C--0106 ROD, CONNECTING 1
6 HW--49050 WASHER, FLAT, SAE 17
7
C--0134 PIN, ROCKER ARM PIVOT 1
2
8 C--0102 ARM REF.
9 HW--51390 SCREW, SOC. HD., CAP, 1
10
HW--51380 SCREW, SOC. HD., CAP, 1
HW--60200 NUT, NYLON INSERT, 1
11 C--0115--A SLIDE, ARM WELDMENT 1
12 HW--66120 BEARING, BALL 2
13
C--0108 BLOCK, SLIDE ARM BEARING 1
HW--51380 SCREW, SOC. HD. CAP, 3
HW--57250 PIN, SPRING, 2
14 HW--61140 RING, RETAINING 1
15 HW--51450 SCREW, SOC. HD., CAP, 4
16 HW--57280 PIN, SPRING, 2
17
HW--51410 SCREW, SOC. HD. CAP, 2
HW--60200 NUT, NYLON INSERT, 2
18 HW--52212 STUD, THREADED, 1
