5 SCOTTY 5000 PARTS
5.47 PLASTIC CUT - BASE
5-97
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
C--0244 PLATE, GUIDE 1
HW--51080 SCREW, SOC. HD. CAP, 3
2
C--0239 GUIDE, LOWER TIP 1
HW--53060 SCREW, BUTTON HD., 2
HW--49220 WASHER, LOCK 2
HW--49030 WASHER, FLAT 2
3 C--0243 PLATE, PLASTIC FEED & CUT 1
4
C--0211 SIDE GUIDE (FOR 1--5/8” MYLAR) 1
C--0246 SIDE GUIDE (FOR 1” MYLAR) 1
HW--53015 SCREW, BUTTON HD., 2
5 HW--51080 SCREW, SOC. HD. CAP, 4
6 HW--53060 SCREW, BUTTON HD., 2
7 C--0242 PLATE, PLASTIC RETAINER 1
8 C--0132 PLATE, TAPPING 1
9
C--0227 ADAPTER, PLASTIC RETAINER 1
HW--51210 SCREW, SOC. HD. CAP, 2
10 HW--61130 RING, RETAINING 2
11 C--0229 SHAFT, RETAINER 1
12
C--0228 RETAINER, SHAFT 1
HW--51430 SCREW, SOC. HD. CAP, 2
13
C--0224 GUIDE, BAR BRACKET, R.H. 1
HW--51430 SCREW, SOC. HD. CAP 2
14 HW--64070 BUSHING, BRONZE 2
15 C--0219 SHAFT, BAR 1
16
C--0218 GUIDE, BAR BRACKET, L.H. 1
HW--51430 SCREW, SOC. HD. CAP, 2
17 HW--61150 RING, RETAINING 2
18
C--0232 COUPLING 1
HW--57030 PIN, SPRING, 2
19 C--0216 ACME SCREW, ADJ. 1
20 HW--82030 SCREW, LOCK 1
21 C--0215 NUT, ADJ. R.H. ACME THREAD 1
22 HW--57250 PIN, SPRING, 4
23
HW--95091 CLAMP-- NYLON, 2
HW--53060 SCREW, BUTTON HEAD, 2
24
HW--95090 CLAMP, NYLON, 1
HW--53060 SCREW, BUTTON HD., 1
25
C--0315 BLOCK, MOUNTING R/H 1
HW--56140 PIN, DOWEL 1
HW--51230 SCREW, SOC HD. CAP, 1
26
C--0307 BLOCK, MOUNTING L/H 1
HW--56140 PIN, DOWEL, 1
HW--51230 SCREW, SOC HD. CAP, 2
27 C--0245 STOP, PLASTIC 1
28 HW--53205 SCREW, BUTTON HD., 1
29 HW--64010 BUSHING, BRONZE 1
To Next Page
