SCOTT Scotty 5000 - Page 234

5 SCOTTY 5000 PARTS
5.48 PLASTIC CUT ASSEMBLY
5-99
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--59060 KEY, SQUARE, 1
2
HW--87090 SPROCKET, 1
HW--52179 SCREW, SOC. SET, 2
3 HW--61160 RING, RETAINING 1
4 HW--66050 BEARING, BALL 2
5
C--0222 CAM, PLASTIC CUT 1
HW--57220 PIN, SPRING, 1
6 C--0101 SHAFT, PLASTIC FEED & CUT 1
7 HW--56186 DOWEL, PULL, 2
8 F--0201 SHAFT, PLASTIC TAB 1
9
F--0202 ARM, PLASTIC TAB 2
HW--57200 PIN, SPRING, 2
HW--51210 SCREW, SOC. HD. CAP, 4
10
HW--55005 SCREW, THUMB NYLON 1
HW--60030 NUT, HEX 1
11 C--0202 PLASTIC, TAB RETAINER 1
12
C--0236 WINDOW 1
HW--54010 SCREW, FLAT HD., 2
13
F--0203 ADAPTER, VACUUM 1
HW--53150 SCREW, BUTTON HD., 4
14
HW--55015 SCREW,SHOULDER, 1
HW--60165 NUT, NYLON INSERT, 1
15
C--0102 ARM 1
HW--51480 SCREW, SOC HD. CAP, 1
16 HW--69220 THRUST RACE, 1
17 C--0204 ROD, CONNECTING 1
18 HW--57170 PIN, SPRING, 3
19 C--0203 BLOCK, ADAPTER 1
20 C--0220 PLATE, SPRING RETAINER 1
21
C--0226 PLATE, BEARING, R.H. 1
HW--51200 SCREW, SOC. HD. CAP, 2
HW--57160 PIN, SPRING, 2
22
C--0221 PLATE, BEARING, L.H. 1
HW--51200 SCREW, SOC. HD. CAP, 2
HW--57160 PIN, SPRING, 2
23 HW--66010 BEARING, BALL 2
24
HW--56220 PIN, DOWEL, 1
HW--61210 RING, RETAINING 2
25 HW--57250 PIN, SPRING, 1
26 HW--57120 PIN, SPRING, 1
27 HW--71030 CAM, FOLLOWER 1
28 C--0205 CUT, CAM FOLLOWER 1
29 HW--51210 SCREW, SOC. HD. CAP, 2
30
HW--70070 ROD END, FEMALE 2
HW--52120 SCREW, SOC. 2
31 HW--69030 THRUST RACE 1
32 HW--79180 SPRING 1
33 C--0235 SPACER, SPRING 1
34 HW--99030 HOSE, VACUUM, 1
