5 SCOTTY 5000 PARTS
5.49 PLASTIC REEL HOLDER
5-101
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
F--1518 ROLLER, SPACER 1
HW--51200 SCREW, SOC. HD. CAP, 1
HW--49040 WASHER, FLAT, 1
2 HW--69140 THRUST RACE 4
3 C--1517 ROLLER, PLASTIC GUIDE 2
4 HW--69190 THRUST RACE 2
5 HW--61230 RING, R ETAINING 2
6 C--1512 SHAFT, ROLLER 4
7 HW--61200 RING, R ETAINING 14
8
F--1501 SHAFT, ROLLER 1
HW--51200 SCREW, SOC. HD. CAP, 2
HW--49040 WASHER, FLAT, 2
9 C--1516 ROLLER, PLASTIC GUIDE 3
10 C--1515 SHAFT, ROLLER 4
11 HW--60120 NUT, HEX, 1
12
C--1534 NUT, PLATE 1
HW--57030 PIN, SPRING, 2
HW--51070 SCREW, SOC. HD. CAP, 2
13 C--1535--A HUB, UNWIND T ENSION ARM 1
14 C--1508 SHAFT, RETA INER 1
15 C--1513 ROLLER, PLASTIC GUIDE 3
16
C--1505 PLATE, PLASTIC MTG. HUB 1
HW--55360 SCREW, DRIVE P--K, 3
17 HW--79050 SPRING, 3
18 C--1509 HUB, PLASTIC MOUNTING 1
19 C--1511 PLUNGER, PLASTIC MOUNTING HUB 3
20 HW--66040 BEARING, BALL 2
21 HW--62050 RING, RETAINING 2
22 C--1533--1 SPINDLE, PLASTIC UNWIND 1
23
HW--52090 SCREW, SOC. SET, 1
HW--84020 BALL, NYLON, 1
24
HW--52201 SCREW, SOC. 1
HW--84030 BALL, NYLON, 1
25 C--1503 COUNTER WEIGHT 1
26 C--1504 ROD, COUNTER WEIGHT 1
27
C--1501 SUPPORT, ROLLER 1
HW--51200 SCREW, SOC. HD. CAP, 2
HW--49040 WASHER, FLAT, 2
