SCOTT Scotty 5000 - Page 242

5 SCOTTY 5000 PARTS
5.52 PAPER TRAY ASSEMBLY
5-107
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 F--1207 BLOCK, MTG. RH. 1
2 HW--51380 SCREW, SHC., 4
3
F--1204 BLOCK, MTG. 2
HW--52020 SCREW, SET, 4
4 F--1212 STRAP, PAPER 2
5
C--2146 PLATE, STRAP 2
HW--53070 SCREW, BUTTON HD., 4
6 HW--81010 KNOB, 2
7 F--1214 BLOCK, STRAP MTG. 2
8 F--1218 ROD, PAPER DEFLECTOR 1
9
F--1213 BRACKET, MTG. 2
HW--51230 SCREW, SHC., 4
HW--52020 SCREW, SET, 2
10 F--1220 SHAFT, MTG. 2
11
F--1205 DEFLECTOR, PAPER 1
HW--53150 SCREW, BUTTON HD., 4
12 F--1206 BLOCK, MTG. LH. 1
13
HW--81010 KNOB
(STANDARD)
2
HW--55470 SCREW, THUMB,
(LONG. SHT. OPTION)
2
14
F--1208 BLOCK, SLIDE (STANDARD) 2
F--1231 BLOCK, SLIDE (LONG. SHT. OPTION)
15
F--1209 STOP, PAPER TRAY (STANDARD) 2
F--1232 STOP, PAPER TRAY
(LONG. SHT. OPTION)
2
16
F--1210 TRAY, PAPER LH. 1
HW--54090 SCREW, FLAT HD., 8
17
F--1211 TRAY, PAPER RH. 1
HW--54090 SCREW, FLAT HD., 8
18 F--1221 COVER 2
19 F--1233 DEFLECTOR, TRAY, PAPER
(LONG. SHT. OPTION)
1
