5 SCOTTY 5000 PARTS
5.53 GUARDS & COVERS
5-109
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1
F--1234 COVER, TOP, LEXAN CLEAR 1
HW--54092 SCREW, FLAT HD, 8
2 F--1237 YOKE, FRONT 2
3 HW--60140 NUT, HEX JAM 24
4 F--1222 STUD, GUARD MTG. 2
5 F--1202 COVER, REAR 1
6 HW--60340 NUT, HIGH CROWN HEX 8
7 F--1223 STUD, GUARD MTG. 2
8
F--1225 COVER, DRIVE RH 1
HW--53150 SCREW, BUT HD 4
9
F--1224 COVER, DRIVE--L.H. 1
HW--53150 SCREW, BUT HD 4
10 C--0905 STUD, GUARD MTG. 2
11 F--1201 COVER, FRONT 1
12 C--0904 STUD GUARD MTG. 2
13 F--1219 COVER 1
14 HW--53060 SCREW, BUT HD 2
15 F--1238 YOKE, BACK 2
16 HW--54032 SCREW. FLAT HD 2
17
HW--97050--SA SENSOR & ACTUATOR, 1
HW--60010 NUT, HEX 2
HW--49010 WASHER, FLAT 2
18 HW--53030 SCREW, BUT HD. 2
19 HW--57260 PIN, SPRING 2
20 HW--51230 SCREW, SHC 2
21 HW--49240 WASHER, NYLON 8
22 HW--99060 TUBING, SHRINKABLE, 1
23 HW--97054 RECEPTACLE, MALE 1
24 F--1236 SUPPORT, RAIL R.H. 1
25 F--1235 SUPPORT, RAIL L.H. 1
26
F--1226 LEGEND PLATE, REEL HOLDER 1
HW--55353 DRIVE SCREW, 4
27
F--1227--1 LEGEND PLATE, PLASTIC POSITION 1
HW--55353 DRIVE SCREW, 2
28
F--1228--1 LEGEND PLATE, PLASTIC SIZE 1
HW--55353 DRIVE SCREW, 2
29
F--1229--1 LEGEND PLATE, TAB POSITION 1
HW--55353 DRIVE SCREW, 2
30
F--1230--1 LEGEND PLATE, TAB SIZE 1
HW--55353 DRIVE SCREW, 2
