5 SCOTTY 5000 PARTS
5.54 BASE & DRIVE
5-111
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 F--1101 MACHINE BASE 1
2
C--8702 SPROCKET, CROSS SHF, 2
HW--52080 SCREW, SOC. SET, 4
3 C--0907 PIN, IDLER 1
4
C--8706 SPROCKET, IDLER, 2
HW--62030 RING, RETAINING 4
5 HW--66020 BEARING, BALL, 12
6 HW--51380 SCREW, SOC. HD. CAP, 1
7
HW--87090 SPROCKET DRIVE SHF, 1
HW--52100 SCREW, SOC. SET, 2
HW--59060 KEY, SQUARE, 1
8 C--0910 BLOCK, CHAIN TAKE UP 1
9
C--0906 BLOCK, ADJUSTMENT 1
HW--51490 SCREW, SOC. HD. CAP, 2
10 HW--52250 SCREW, SOC. SET, 1
11
C--0909 RETAINER 1
HW--51410 SCREW, SOC. HD. CAP, 2
12 HW--60140 NUT, HEX JAM, 1
13 HW - -61110 RING, RETAINING 2
14 C--0908 PIN, SPROCKET 1
15 HW--51400 SCREW, SOC. HD. CAP, 1
16 HW--71030 YOKE, ROLLER 1
17 HW--49050 WASHER, FLA T 1
18
HW--51410 SCREW, SOC. HD. CAP, 2
HW--49050 WASHER, FLAT, 2
19 F - -1110 - -1 BLOCK, ROLLER 1
20 HW--61160 RING, RETAINING 2
21 HW--66050 BEARING, BALL 2
22 F--1102 PLATE, MAIN MACHINE L.H. 1
23
C--1102 SHAFT, DRIVE PLAIN 1
HW--59070 KEY, SQUARE, 1
24 HW--87120 SPROCKET DRIVE SHF 1
25 HW--87170 TENSIONER 1
26 HW--87140 SPROCKET, IDLER 1
27 HW--60270 NUT W/ NYLON INSERT, 1
28
F--1108 HOUSING, BEARING 1
HW--51230 SCREW, SOC. HD. CAP, 3
29
C--0210 HOUSING, BEARING 1
HW--51230 SCREW, SOC. HD. CAP, 4
30 HW--57030 PIN, SPRING, 8
31
F--1125 ROD, DRIVE 2
HW--58010 KEY, WOODRUFF, 2
32
F--1107 SHAFT, CROSS (REMOVABLE) 2
F--1121 PLATE, NUT (PARTOFSHAFT,CROSS) 4
HW--53160 SCREW, BUTTON HD., 8
33 F--1124 ROD, CROSS SHAFT 2
34 F--1103 PLATE, MAIN MACHINE R.H. 1
35
HW--98050 COLLAR, 1
HW--55370 SCREW, HEX HD., 1
36
HW--97080 BRACKET, SENSOR 1
HW--53070 SCREW, BUTTON HD., 2
HW--49030 WASHER, FLAT, 2
37 HW--97099 SENSOR, PROX 1
38
HW--97017 AMPLIFIER 3
HW--51080 SCREW, SOC HD. CAP, 6
HW--49030 WASHER, FLAT, 6
F--1604 BRACKET, SWITCH 3
HW--97018 ADAPTER, CORD 3
HW--51026 SCREW, SOC HD., 6
39
F--1126 BLOCK, MOUNTING 1
HW--53140 SCREW, BUTTON HD. 2
40 F--1127 ROD, GUARD 1
41 HW--49100 WASHER, FLAT HARDEN, 1
To Next Page
