5 SCOTTY 5000 PARTS
5.55 MAIN MOTOR & VACUUM PUMP
5-113
F--9999--8 08/2006 Issue 1
ITEM # PART # DESCRIPTION #REQ ITEM # PART # DESCRIPTION #REQ
1 HW--55380 SCREW, HEX HD., 4
2 F--1105 PLATE, MOTOR MOUNTING 1
3 HW--51380 SCREW, SOC. HD. CAP, 4
4
C--4701--1 VACUUM PUMP, GAST 1
HW--95094
RECEPTACLE 3 PIN MALE
1
HW--55370 SCREW, SOC. HD. CAP, 4
HW--49050 WASHER, FLAT, 4
HW--63310 ELBOW, 2
HW--95215 TERMINAL, RING 1
HW--95216 CONNECTOR, SLIP--ON 2
5 F--1106 REDUCER, RIGHT ANGLE/
SUPPLIED WITH:
BOLT, HEX HD.,
WASHER, LOCK,
KEY,SHAFT,
1
4
4
1
6
HW--87150 SPROCKET, REDUCER 1
HW--52100 SCREW, SOC. SET, 2
7
F--1104 DC MOTOR 1
HW--95093 RECEPTACLE 4 PIN MALE, 1
HW--95180 CONNECTOR, BUTT END 2
HW--95215 TERMINAL, RING 1
8 HW--51470 SCREW, SOC. HD. CAP 8
9 HW--56250 DOWEL, PIN, 4
10 F--9700 ELECTRICAL PANEL ASS’Y 1
11
HW--51480 SCREW, SOC. HD. CAP, 4
HW--49110 WASHER, FLAT HARDENED, 4
12
F--1601 BRACKET, J--BOX 2
HW--51200 SCREW, SOC HD. CAP, 8
13
F--1120 BRACKET, VALVE 1
HW--51210 SCREW, SOC HD. CAP, 2
14
F--1123--1 MAC VALVE 1
HW--51250 SCREW, SOC HD. CAP, 2
15 HW--47180 MUFFLER 1
16 HW--63300 FITTING, MALE, 1
17 HW--63310
ELBOW,
1
18
HW--95074 RECEPTACLE BOX, 1
HW--51200 SCREW, SOC HD. CAP, 2
HW--95073 VACUUM RECPT., 1
HW--95092 RECEPTACLE 3 PIN MALE 1
19 HW--63320 FITTING, MALE, 1
20
HW--95010 CHANNEL, 2
HW--53140 SCREW, BUTTON HD., 2
21 F--1603 NAME PLATE, MAIN MACHINE 1
