3 Operation
3--20
F--9999--8 Build 8 Issue 1
DRAG ROLLER KNOB
MYLAR FILM
TOP VIEW
ROLLER GUIDE
ROLLER
FRONT VIEW
ROLLER
MYLAR
ROLLER GUIDE
MYLAR
Fig. 3-38. Inspect Plastic Feed Tracking
Step: 21.If Mylar is tracking behind the fold and drive rollers, move roller to the right as shown in Fig. 3-38.
