Sekonic SPECTROMASTER C-800 User Manual

102
6. Measurement Tool [Tool Box] Screen
6.
Measurement Tool [Tool Box] Screen
Selecting Screens from the Tool Box
Touch the [Tool Box ( )] icon in the Measuring screen to display the Tool Box
screen. (

P15) You can select screens from the Tool Box as follows.
Memory Management
Screen (

P110)
Tool Box Screen
Preset Selection Screen
(

P103)
Memory Title Screen
(

P107)
Return to the Measuring
Screen by touching the
[Close] button.
The set content is
displayed in yellow letters
at the lower right hand
corner of the button.

Sekonic SPECTROMASTER C-800 Specifications

General

Type	Spectrometer
Color Temperature Range	1, 600 to 40, 000 K
Spectral Wavelength Range	380 to 780 nm
Power Source	Rechargeable lithium-ion battery
Operating Temperature	0 to 40°C (32 to 104°F)
Display	Color LCD
Measurement Range	1 to 200, 000 lx
Spectral Response	Human eye response
Connectivity	USB
Weight	350 g (including battery)
Memory Capacity	Up to 1, 000 measurements
