Sekonic SPECTROMASTER C-800 User Manual

143
7. Meter Settings [Setting] Screen
7-2-9 Selecting the Spectrum Y-axis Scale
Select Relative, Auto, or any specic number of spectral irradiance as the maximum
display value for the spectrum Y-axis.
Operation
1.
Touch the item [Spectrum Y-axis Scale] button on page 2 of
Setting.
The maximum display value of the spectrum Y-axis scale will be displayed.
Spectrum Y-axis Scale Screen
Spectrum Y-axis Scale Screen
Default
Setting Screen

Sekonic SPECTROMASTER C-800 Specifications

General

Type	Spectrometer
Color Temperature Range	1, 600 to 40, 000 K
Spectral Wavelength Range	380 to 780 nm
Power Source	Rechargeable lithium-ion battery
Operating Temperature	0 to 40°C (32 to 104°F)
Display	Color LCD
Measurement Range	1 to 200, 000 lx
Spectral Response	Human eye response
Connectivity	USB
Weight	350 g (including battery)
Memory Capacity	Up to 1, 000 measurements
