Sekonic SPECTROMASTER C-800 User Manual

145
7. Meter Settings [Setting] Screen
NOTE
Relative...............................Regardless of brightness of light source, the peak of brightness
in each measurement and memorized values is regarded as 1.0
to compare the light sources in shape of spectrum graph.
Auto .................................... The appropriate Y-axis value is automatically selected and
spectral irradiance can be compared.
Spectral Irradiance .............Specic value can be selected from 1.0u to 100 W·m
-2
·nm
-1
.
Relative Auto Spectral Irradiance

Sekonic SPECTROMASTER C-800 Specifications

General

Type	Spectrometer
Color Temperature Range	1, 600 to 40, 000 K
Spectral Wavelength Range	380 to 780 nm
Power Source	Rechargeable lithium-ion battery
Operating Temperature	0 to 40°C (32 to 104°F)
Display	Color LCD
Measurement Range	1 to 200, 000 lx
Spectral Response	Human eye response
Connectivity	USB
Weight	350 g (including battery)
Memory Capacity	Up to 1, 000 measurements
