Section 4
Configuring the SEL-734B
Overview
Refer to this section once the SEL-734B Capacitor Bank Control is turned on
and connected to the switches and sensors.
This section details the procedure to perform the following actions:
➤ Check the status of the SEL-734B
➤ Establish communication with ACSELERATOR QuickSet
®
SEL-5030 Software
➤ Check device status through the front-panel menu
Initial
Communications
Configuration
There are three ways to communicate with the SEL-734B:
➤ Using the front-panel menus and pushbuttons
➤ Using QuickSet
➤ Using a command line interface on a PC terminal emulation
window
Record the Part Number and Serial Number of the
Device
The part number and serial number are located on the side label of the
SEL-734B and also inside the enclosure door.
Establish SEL Communication Between PC and the
SEL-734B
Step 1. Install QuickSet and the SEL-734 Settings Driver.
Step 2. Connect an SEL-C234, SEL-C287, SEL-C662, or an equivalent
serial cable to Port F or Port 2 and to the PC (Port 3 is reserved
for Distributed Network Protocol [DNP3] communications).
Step 3. Run QuickSet.
Step 4. To access the communications parameters in QuickSet, select
Communications > Parameters.
