C.2
SEL-734B Capacitor Bank Control Field Reference Guide Date Code 20170207
Installation Examples
Full-Size Enclosures With the Combined Sensor Connector
Figure C.1 Full-Size Enclosure With Combined Sensor Connector (With a Single Cable for Phase and Neutral
Sensors)
Control
Power
Transformer
SEL-734B
Enclosure,
Combined
Sensor
Connector
A-Phase
B-Phase
C-Phase
Neutral
Three
Single-Phase
Switches
Capacitor
Bank
Control Cable
(SEL-C543, SEL-C544, SEL-C547)
Sensor Cable
(Lindsey Mfg R-22748/XX,YY)
Combo
Sensor
Combo
Sensor
Combo
Sensor
Neutral
Current
Sensor
14-pin 19-pin
Cabinet
Ground Lug
