Sel SEL-734B - Figure C.3 Full-Size Enclosure with Individual Sensor Connectors (Installed with a Lindsey Neutral Current Sensor)

C.4
SEL-734B Capacitor Bank Control Field Reference Guide Date Code 20170207
Installation Examples
Full-Size Enclosures With the Combined Sensor Connector
Figure C.3 Full-Size Enclosure With Individual Sensor Connectors (Installed With a Lindsey Neutral Current
Sensor)
Control
Power
Transformer
A-Phase
B-Phase
C-Phase
Neutral
Three
Single-Phase
Switches
Capacitor
Bank
Combo
Sensor
Combo
Sensor
Combo
Sensor
Neutral
Current
Sensor
SEL-734B Enclosure, Individual
Sensor Connectors
Sensor
Connectors
Individual
Sensor Cables
(SEL-C530, Lindsey 9-587/XX/9-582)
Control
Connector
Power Supply/
Neutral Sensor
Connector
Power Supply/Neutral Sensor Cable (SEL-C539)
Control Cable
(SEL-C531, SEL-C537,
SEL-C538)
4-pin
connectors
Lindsey R-22981SS
Cable and
Neutral Sensor
Cabinet
Ground Lug
