Appendix D
Cable Drawings
This appendix includes cable drawings for each enclosure style.
Control Cables for Full-Size Enclosures With the
Combined Sensor Connector
SEL-C543
Cable SEL-C543 connects to three switches and the control power
transformer (5-pin female connectors).
J1
Phase 1
Phase 2
Phase 3
Power Supply
J2
J3
J4
Jacket:
• SOOW Cable
• 6 Conductor, 16 AWG
• Super Vu-Tron 90°C, Black
• Temperature Range:
–40° to 90°C
Industry Approvals:
• UL Flexible Cord UL Subject 62
• CSA Flexible Cord C22.2-49
• MSHA Approved
• RoHS Compliant
• Military Standard
• 3106 Style
• Insert Arrangement 22-14S
• Solid Backshell
• Maximum Diameter: 1.340 inch
• Military Standard
• 3106 Style
• Insert Arrangement 18-11S
• Solid Backshell
• Maximum Diameter: 1.22 inch
• Shielded SO0W Cable
• UL Standard 62
• UL and CSA Listed
• Temperature Rating: 90°C
• Voltage Rating: 600 V
• 2 Conductor, 12 AWG
Wire Color
Black
White
Red
White
Green
Black
Orange
Red
White
Green
Black
Orange
Red
White
Green
Black
Orange
120 VAC
Neutral
Common
Common
Close
Open
52b
Common
Common
Close
Open
52b
Common
Common
Close
Open
52b
Wire Type
#12 AWG 65/30 Strand
#12 AWG 65/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
#16 AWG 26/30 Strand
Connector Pin
J1-A
J1-B
J1-U
J1-E
J1-D
J1-C
J1-N
J1-U
J1-H
J1-G
J1-F
J1-R
J1-U
J1-L
J1-K
J1-J
J1-T
Connector Pin
Wire Termination
Wire Termination
J2-A
J2-B
J2-C
J2-D
J2-E
J3-A
J3-B
J3-C
J3-D
J3-E
J4-A
J4-B
J4-C
J4-D
J4-E
Function
Phase 1
Power Supply
Phase 2
Phase 3
