Date Code 20170207 Field Reference Guide SEL-734B Capacitor Bank Control
Section 5
Working With the SEL-734B
Design Template Settings
Overview
An SEL-734B Capacitor Bank Control ordered in an enclosure comes with a
pre-installed design template. Templates, designed for capacitor bank control,
are also available on the SEL website.
Enclosure Model Features
The design templates are specific to each model option available for the
SEL-734B. Table 5.1 provides a complete reference about the available
options.
Table 5.1 Control Features of Enclosure Models
Available Control
Strategies
Enclosure/Field Interface
Full Size
Compact
4-Jaw 6-Jaw Option A 6-Jaw Option B 7-Pi n
Ganged Phase Control x x x x x
Individual Phase Control x
Voltage Control x x x x x
kVAR Control x x x x
Power Factor Control x x x
Current Control x x x
Time-Based Control x x x x
Available Features
Adaptive Voltage and
kVAR Processing
xxx
Neutral Unbalance Alarm
and Lockout
xx x
Switch Monitoring x
Capacitor Fault Detection x x x
Integrated 15 Vdc Power
Supply
xxxxx
