Date Code 20170207 Field Reference Guide SEL-734B Capacitor Bank Control
Appendix F
Accessories
Compact Enclosure Accessories
This section describes the cables and accessories available with the SEL-734B
compact enclosures.
Mounting
Control and
Measurement
Security Sleeves
The security sleeve for the connectorized enclosure style shrouds the cable
connection to prevent vandalism. The sleeve is made from stainless steel.
Full-Size Enclosure Accessories
This section describes the cables and accessories available with the SEL-734B
Full-Size Enclosures.
Mounting
A factory-installed pole-mounting bracket is an ordering option for the full-
size enclosure (see Figure 3.2). It is not available as a field-installed accessory.
Part Number Description
915900302 Meter locking ring. Compatible with the 4-jaw and 6-jaw socket-
based enclosure styles.
915900298 Pole-mounting bracket. Compatible with the 7-pin connectorized
enclosure style (see Figure 3.3).
Part Number Description
SEL-C548 Control and sensor cable. Compatible with the 7-pin connectorized
enclosure style. Connects to the following equipment:
➤ Control power transformer
➤ One trip/close switch circuit
➤ One phase current sensor
➤ One neutral current sensor
Part Number Description
9250011 Security sleeve for the 7-pin connectorized enclosure style.
Part Number Description
915900448 Two stainless steel pole-mounting straps, 9-1/2” to 12-1/4” in diam-
eter. Compatible with factory-installed mounting bracket.
